GAC Engine Speed Control Unit Speed Controller Droop Governor EG2000
Model: EG2000
Compatible EG2000 engine speed governor at factory price. 100% bench-tested, 13-month warranty, in stock. Request wiring diagram, datasheet & quote.
| Warranty | 13 months |
|---|---|
| Place of Origin | Fujian, China |
| Brand Name | POPULACE |
| Model Number | EG2000 |
| Working Voltage | 10-32V DC |
| Output Current Range | Continuous 7A. Max. 15A for 10s |
Applications
- Mechanical and electronic speed control of GAC diesel engines driving generator sets
- Prime-power sets where load steps demand fast, stable frequency recovery
- Pump and compressor engine packages requiring droop or isochronous governing
Product Description
GAC Engine Speed Control Unit Speed Controller Droop Governor EG2000
 | GAC Engine Speed Control Unit Speed Controller Droop Governor EG2000 The EG2000 is a universal generator governor / engine speed controller equipped with Smoke Limiting, & Idle Speed. Suitable for diesel, gas and natural gas engines with Built-in & Non-Built-in PTs Pumps, also can be used with Low Current, Electric over Hydraulic Oil Pumps Type Governor Actuators. |
 | Features *Works on a wide ranges of MPU/flywheel frequencies *15 Amp Max Output *Suitable for all types of diesel and Gas engines *High Sensitivity and stable at Low Frequency Variations *Moisture, vibration, and rust protected, Epoxy encapsulated electronics *For Use With Isochronous Generators & Automatic Paralleling PLC controls *Idle Speed Adjustment and connections for a Remote Speed POT |
| EG2000 | |
| Operating Voltage | 12 or 24 VDC ±20% |
| Output Current | 0.5 ~ 15 A |
| Run Speed Adjustment range | Speed adjustment Potentiometer (30 turn); 4 Segment Dip Switch Adjustable From 600 ~ 9500 Hz. |
| Idle Speed Adjustment Range | Run Speed 30 ~ 85% |
| Ramp Time | 3 ~ 20 Sec |
| Remote Speed Pot | Ext. Remote speed pot terminal 6, 7, 8 (ILS) and 6, 7, 9 Connect a 5K potentiometer ±5% adjustment range. |
| Temp. Stability | <0.01% |
| Run Speed Stability | ± 0.25 % at steady state |
| MPU input signal | 1 ~ 120VAC RMS |
| Droop | 4.00% |
| Adjustment | Run Speed, Idle Speed, Ramp Time, Droop, Integration, Gain |
| Mechanical Vibration | 1G @ 18 ~ 30 Hz, 2.5G @ 48 ~ 70 Hz |
| Relative Humidity | < 95% |
| Operating Temperature | -40 ~ 85°C |
| Storage Temperature | -40 ~ 85°C |
| Dimensions | 147mm L * 114mm W * 50mm H |
| Weight | 690g ± 2% |
There are no reviews yet.
Be the first to review “GAC Engine Speed Control Unit Speed Controller Droop Governor EG2000”
Your email address will not be published. Required fields are marked *
Related Products
Compatible generator parts & matching system accessories.
Technical Guides & Troubleshooting
Engineering diagnostics, terminal wiring diagrams, and parts replacement procedures.
Generator Engine Hunting: How to Diagnose Governor Instability
Hunting - the engine speed oscillating in a steady rhythm - is a governor-loop problem, not an engine problem. Work outside-in: linkage free play first, then sensor signal, then the controller’s gain and droop settings.
Read Guide → Engineering GuideDiesel Generator Parts Catalog & OEM Replacement Selection Guide
A practical guide to selecting compatible diesel generator replacement parts, covering AVRs, control modules, speed governors, fuel shut off solenoids, and battery chargers.
Read Guide →FAQ
governor EG2000 is an Compatible speed control unit. Tell us your engine model and rated RPM and we confirm linkage, droop range and actuator compatibility before shipping.
Yes. Each unit is bench-run for response and droop linearity before dispatch, and the test record travels with your order.
governor EG2000 is covered by a 13 months factory warranty. Quality issues within the term are replaced or repaired at our cost.
Yes. POPULACE Electronic Co., Ltd. manufactures generator parts in Xiamen, Fujian - factory visits are welcome.
Yes. Samples are available for testing; express freight (FedEx, DHL, UPS, TNT, Aramex) typically delivers within 3-7 days.
In-stock items ship 2-3 days after payment; larger batches are produced in 3-7 days. Sea, air or express shipping is arranged to your preference.
T/T, PayPal, Western Union, MoneyGram, Alibaba order link and RMB transfer are all supported.
Yes. Detailed terminal connection wiring diagrams and user manuals for EG2000 are available upon request. Contact our technical support with your generator setup to receive the documentation.
The technical datasheet and complete specification sheet for EG2000 can be provided directly by our sales team. Contact [email protected] or submit an inquiry to receive the PDF specification.
